XLS-D Series High Configuration Semi-Automatic Printing Slotting Die-Cutting Machine
Adopt the international high-grade printing mechatronics design concept.With beautiful appearance, compact structure and high degree automation.High quality printing quality, high topping accuracy, convenient adjustment.
Keywords:
Classification:
Carton printer slotter die-cutter machine
Product details
MACHINE FEATURES
◎ Adopt the international high-grade printing mechatronics design concept.
◎ With beautiful appearance, compact structure and high degree automation.
◎ High quality printing quality, high topping accuracy, convenient adjustment.
◎ Electrically control unit separation, pneumatic locking, pneumatic roller lifting, automatic ink distribution, electric control phase.
◎ Transmission part: expansion sleeve connect, cross slider no gap adjustment, ensure high printing precision, small slotting error, and keep unchanged for a long time.
◎ The gear is made of 40Cr material by quenching and tempering, gear shaving, and equipped with spray lubrication and oil level balancing device, which greatly improves the service life of the gear.
◎ With Taiwan Maxdura rubber and imported zig zag blade, with have long service life and high durability.
Technical Parameters
|
Parameter |
Unit |
Model |
|||||
|
336*2600 |
408*2600 |
480*2600 |
540*3000 |
600*3000 |
700*3400 |
||
|
Inner width |
mm |
2600 |
2600 |
2600 |
3000 |
3000 |
3400 |
|
Max feeding size |
mm |
980*2400 |
1200*2400 |
1420*2400 |
1600*2800 |
1800*2800 |
2100*3200 |
|
Min feeding size |
mm |
270*600 |
330*600 |
350*600 |
400*700 |
450*700 |
500*800 |
|
Max printing size |
mm |
980*2250 |
1200*2250 |
1420*2250 |
1600*2650 |
1800*2650 |
2100*3050 |
|
Design speed |
Pcs/min |
120 |
120 |
110 |
100 |
100 |
100 |
|
Max running speed |
Pcs/min |
100 |
100 |
90 |
80 |
80 |
80 |
|
Printing accuracy |
mm |
±0.5 |
±0.5 |
±0.5 |
±0.5 |
±0.5 |
±0.5 |
|
Standard plate thickness |
mm |
4-6 |
4-6 |
4-6 |
4-6 |
4-6 |
4-6 |
|
Cardboard thickness |
mm |
2-11 |
2-11 |
2-11 |
2-11 |
2-11 |
2-11 |
